ZALMAN CNPS2X User Manual

7
.COM
E. Cooler Installation
① Apply a suitable amount of thermal grease on the center of the CPU, then mount the
heatsink and fasten the installation bolts based on the CPU socket type.
When installing the heatsink on a tower case, make sure the heatpipe on the
base is parallel to the ground, as installing it perpendicularly may limit the cooling
performance.
Intel Clip AMD Clip
AMD Socket
Heatpipe Heatpipe
Unused mounting hole
Intel Socket 1156/1155/1150
Intel Socket 775
Intel or AMD CPU
Caution
O
X
