ZALMAN CNPS2X - Backplate Installation

6
.COM
Intel Socket 1156 / 1155 / 1150 / 775 AMD Socket FM2/FM1/AM3+/AM3/AM2+/AM2
- Align the Backplate’s nuts with
motherboard’s clip support holes, attach
it to the back side of the motherboard.
① Take away the fixed Clip support from
the motherboard.
② Align the Backplate with motherboard’s
clip support holes, attach it to the back
side of the motherboard.
D. Backplate Installation
M/B
M/B
M/B
