Please note that the sticky side of the
Loading Block serves to attach the
Loading Block to the backplate.
② Peel off one side of the Double-sided Tape
and attach it with the sticky side facing the
Loading block. Then, peel off the top cover.
① Peel off the Loading Block cover and
attach it to the Backplate with the sticky
side facing the center of the Backplate.
Caution
Intel Socket 1156 / 1155 / 1150
※ Intel
Socket 1156/1155/1150 Installation does not require the Loading Block.
Intel Socket 775
AMD Socket FM2/FM1/AM3+/AM3/AM2+/AM2
C.
Double-sided Tape and Loading Block Installation
To Next Page
