GS1000
3) PSU Installation
(1) PSU Bracket Removal
(2) PSU Bracket Assembly
B TypeA Type
B TypeA Type
▶A Type : Please position the PSU’s intake facing downwards to optimize PSU
cooling.
▶B Type : Please position the PSU’s intake facing upwards to optimize system
cooling.
※ If the system is in a dusty environment, please use the B Type configuration.
Tip
PSU Screw
