Zanotti BAS235T02F - Page 49

DATA:
REV.nr. FOGLIO nr :
DI
33
BDB340TO02F-298F-315F-TO311F/ANP
BDB340NO02F-86F-305F-315F/ANP
HCD631NO02F
AA10002
04-04-2003Soncini
DISEGNO nr.
ApprovatoDisegnato
Soncini
DATA: Approvato
MODELLO
01
23-11-2004 SONCINI
sez. cavo resistenze
EVAPORATORCONDENSING UNIT
TO X3
TO X2
TO X2
FROM X1
FROM X1
FROM X1
RIGHT
LEFT
S1051Y=21,0 A
S1556Y=31,0 A
BDB340NO...F
BDB340TO...F
4 x 4,0 mmq
5 x 10,0 mmq
CAVO DI LINEA
( LINE CABLE )
COMPRESSORE
(COMPRESSOR)
MACCHINA
( UNIT )
CAVO COMPRES.
(COMPRES. CABLE)
VENTOLA COND. VENTOLE EVAP.
(CONDEN. FAN) (EVAP. FANS)
SBRINAMENTO
(DEFROST)
I max.=10,9 A In=2,65 A In tot.=2,19 A
CARATTERISTICHE GENERALI E ASSORBIMENTI
4 x 10,0 mmq
5 x 6,0 mmq
I max.=10,9 A In=2,65 A In tot.=2,19 A
MORSETTIERE
S1051Y=21,0 AHCD631NO02F 5 x 6,0 mmq4 x 4,0 mmq- In=2,65 A -
