72
5.
Coolingcircuit and connection details
Refrigerant diagram key
1 Compressor 12 Pressure regulator valve
2 Check valve 13 Liquid sightglass
3 High pressure switch 14 Dehydrator filter
4 Low pressure switch 15 Condenser fan
5 Condenser battery 16 Heat exchanger
6 Solenoid valve 17 Thermostatic bulb
7 Electric motor 18 Evaporatting battery
8 Condensing units 19 Evaporator fan
9 Evaporatorating units 20 Thermostatic valve
10 Compressor 21 Liquid receiver
11 Oil separator 22 Cock
