Direct drive units
Abbrevia
tion
Type Description Site
220/1/50-60 400/3/50
115/1/60 12V 24V
FS
Primary
transformer fuse
Switchboard 6A 4A (x2) 10A - -
FGR
Secondary
transformer fuse
Switchboard - - - 40A 30A
FGS
CPU protection fuse
stand-by mode
Battery - - - 40A 40A
FB
CPU protection fuse
road mode
MP Board - - - 5A 5A
FR
Secondary
transformer fuse
MP Board - - - 5A 5A
FFR
Stand-by
compressor
protection fuse
MP Board - - - 10A 10A
FFS
Road compressor
protection fuse
MP Board - - - 10A 10A
FSS
Defrosting solenoid
protection fuse
MP Board - - - 10A 10A
F6-F6/1
Condenser fans
protection fuses
MP Board - - - 30A 20A
F8-9-10-
11
Evaporator fans
protection fuses
MP Board - - - 20A 15A
8. HOW TO ORDER SPARE PARTS
When necessary to replace the components of the own unit, both in the event of scheduled maintenance or
breakage, to choose a solution tried and tested, which is able to ensure the same level of performance and safety
of the original plant.
Zanotti designs its parts because they meet extreme demands of the refrigeration systems in vehicles. Invest in
quality and reliability allows to supply spare parts that guarantee a longer life and increased maintenance intervals.
The best way to ensure that your Zanotti unit remains efficient and reliable is to keep 100% Zanotti.
Contact your dealer.
9. DISPOSAL OF PACKAGING
Wooden, plastic, polystyrene packing shall be disposed of in accordance with applicable laws in the country where
the appliance is used
10. DISPOSAL OF THE UNIT
In case of scrapping, the unit components must not be discarded in the environment but must be disposed of by a
licensed company and recovery of waste, in accordance with the laws in force in the country where the machine is
used.
ATTENTION
The refrigerant may not be discharged into the atmosphere, to be recovered and disposed
of by companies dealing with special waste collection.
