5
1. Hob Top
2. Rapid Hotplate - 2090 W/180 mm dia.
3. Normal Hotplate - 1040 W/145 mm dia.
4. Rapid Hotplate - 1570 W/145 mm dia.
5. Normal Hotplate - 1570 W/180 mm dia.
6. Control knob for back left hotplate
7. Control knob for back right hotplate
8. Control knob for front right hotplate
9. Control knob for front left hotplate
9. Electric Hotplates Control Light
DESCRIPTION OF THE HOB
INSTALLATION
The hob must be installed according to the
instructions supplied.
The hob must be installed by qualified
personnel to the relevant British Standards.
Please, ensure that, once the hob is
installed, it is easily accessible for the
engineer in the event of a breakdown.
WHEN THE HOB IS FIRST INSTALLED
Once the hob has been installed, it is
important to remove any protective
materials, which were put on in the factory.
1
3
2
4
5
6
7
8
9
10
