PRODUCT DESCRIPTION
COOKING SURFACE LAYOUT
120/210
mm
120/210
mm
145 mm
145 mm
170 mm
265 mm
170 mm
265 mm
1
1
1 1
2
1
Cooking zone
2
Control panel
CONTROL PANEL LAYOUT
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions
operate.
Sensor
field
Function Comment
1
ON / OFF To activate and deactivate the hob.
2
Lock / Child Safety Device To lock / unlock the control panel.
3
- To activate and deactivate the outer ring.
4
- Heat setting display To show the heat setting.
5
- Timer indicators of cooking
zones
To show for which zone you set the time.
6
- Timer display To show the time in minutes.
7
- To activate and deactivate the outer ring.
7
