Flow chart showing how to use the SET BATTERY TYPE adjustment
1) Opening Zapi Menu.
AC2 ZAPI V0.0
48V 350A 00000
2) Press Top Left & Right Buttons to enter CONFIG
Menu.
% ' %
' ' '
3) The Display will show: SET MODEL.
CONFIG MENU
SET MODEL
4) Press ROLL UP button until
ADJUSTMENTS Menu appears.
% ' '
' ' '
5) ADJUSTMENTS appears on the display.
CONFIG MENU
ADJUSTMENTS
6) Press ENTER to go into the ADJUSTMENTS
Menu.
' % '
' ' '
7) The display will show: SET BATTERY TYPE.
SET BATTERY TYPE
80V
8) Press SET UP to choose nominal value of the
battery.
' ' %
' ' '
9) New battery value appears.
SET BATTERY TYPE
48V
10) Press OUT.
' ' '
' % '
11) Confirmation request appears.
ARE YOU SURE?
YES=ENTER NO=OUT
12) Press ENTER to accept the changes, or press
OUT if you do not accept the changes.
' % '
' ' '
' ' '
' % '
13) Press OUT. Display now shows the Opening
Zapi Menu.
' ' '
' % '
Page - 36/64 ADEZP0AE - AC-2 INVERTER - User Manual
