DESCRIPTION OF EQUIPMENT SECTION 1
%$5&2'(6<0%2/2*,(6
67$1'$5'35,17(5)2176
Bitmap fonts A, B, C, D, E, F, G, H, and GS are expandable up to 10 times, height and width
independently. However, fonts E and H (OCR-A and OCR-B) are not considered “in-spec”
when expanded.
The smooth scalable font 0 (CG Triumvirate™ Bold Condensed) is expandable on a dot-by-
dot basis, height and width independent, while maintaining smooth edges. Maximum
character size depends on available memory.
IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G,
and 0 through software control.
Bar code ratios — 2:1, 7:3, 5:2, & 3:1 Linear bar codes:
2 dimensional bar codes: • Code 11
• CODABLOCK • Code 39
• PDF-417 • Code 93
• Micro PDF-417 • ISBT-128
• Code 49 • UPC-A, UPC Extensions
•Data Matrix •UPC-E
•Maxi Code •EAN-8
•QR-Code •EAN-13
• Code 128 (with subsets A, B, and C and
UCC case C codes)
• UPC and EAN 2 or 5 digit expressions
• Plessey
• Postnet
• Standard 2 of 5
• Industrial 2 of 5
• Interleaved 2 of 5
• LOGMARS
•MSI
• Codabar
Table 1-1. Font Matrices for 8 dot/mm (203 DPI) 105SL Printheads
Font Matrix Type*
Character Size
Inches Millimeters
Height Width
Inter-
character
gap
Height Width
Char./
Inch
Height Width
Char./
mm
A 9 5 1 U-L-D 0.044 0.030 33.9 1.13 0.75 1.33
B 11 7 2 U 0.054 0.044 22.6 1.38 1.13 0.89
C,D 18 10 2 U-L-D 0.089 0.059 16.9 2.25 1.50 0.67
E 28 15 5 OCR-B 0.138 0.098 10.2 3.50 2.50 0.40
F 26 13 3 U-L-D 0.128 0.079 12.7 3.25 2.00 0.50
G 60 40 8 U-L-D 0.295 0.236 4.2 7.50 6.00 0.17
H 21 13 6 OCR-A 0.103 0.094 10.7 2.63 2.38 0.42
GS 24 24 0 SYMBOL 0.118 0.118 8.5 3.00 3.00 0.33
0 variable U-L-D variable
* U = Uppercase, L = Lowercase, D = Descenders
