MAINTENANCE AND ASSEMBLY DRAWINGS SECTION 5
SECTION 5
MAINTENANCE AND ASSEMBLY DRAWINGS
Figure 5-5. Printhead Support Assembly
(See Note 1)
Note:
1. Position Ribbon Sensor Tab not
to be Flush With Top Edge of Pivot Bar.
Gap 0.010 Min./0.030 Max. Below Top Edge
2. Remove Tab as Shown from Printhead
Data Connector. Remaining Printhead Data Connector
Tab must Snap over Connector
Wrap Ground Strap
As Shown
XXXXXXXXXXXXXX R=XXXX
XXXXXX
XXXXXXXXXXX
Resistance Value
1
2
3
4
6
5
6
7
9
10
11
12
13
14
15
16
17
7
18
19
20
21
22
23
24
25
26
27
7
8
28
To Next Page
