Page 5-14 105SL Maintenance Manual 32056L Rev. 2 12/4/01
SECTION 5 MAINTENANCE AND ASSEMBLY DRAWINGS
*Only available in quantities of 25 as Part Number HW30247
**Only available in quantities of 50 as Part Number HW40193
***Only available in quantities of 25 as Part Number HW30392-004
†Only available in quantities of 25 as Part Number HW30423-006
Table 5-6. Main and Lower Platen Rollers
Item Part Number Description Qty
1 32011M Kit, Maintenance, Platen Roller (Main) 1
2 . Assembly, Platen Roller 1
3 . Bearing, Flanged Ball 2
4 . Washer, Flat 0.42 x 0.260 x 0.0747 1
5 02252 . Ring, Crescent External 0.250 1
6 22004-2 .Spacer 1
7 32101M Kit, Maintenance, Lower Platen Roller 1
8 . Assembly, Platen Roller 1
9 . Bearing, Flanged Ball 2
10 . Washer, Flat 0.42 x 0.260 x 0.0747 1
11 02252 . Ring, Crescent External 0.250 1
12 22004-1 .Spacer 1
13 40019 . Plate, Roller Adjust 1
14 . Washer, Flat 0.406 x 0.172 x 0.048 2
15 . Screw, 6-32 x 0.25 2
16 40355M Kit, Maintenance, Platen Pulley (12 & 8 Dots/mm) 1
17
† . Screw, 8-32 x 0.375 2
18 .Pulley 1
19 30914M Kit, Maintenance, Rewind (12 & 8 Dots/mm) 1
20
† . Screw, 8-32 x 0.375 2
21 .Pulley 1
Bold = Part available for purchase
Light italic = Part not available for purchase, listed and shown for reference only
