Page 5-20 105SL Maintenance Manual 32056L Rev. 2 12/4/01
SECTION 5 MAINTENANCE AND ASSEMBLY DRAWINGS
*Only available in quantities of 25 as Part Number HW30118
**Only available in quantities of 50 as Part Number HW30041-1
†Only available as a Service Kit as Part Number 40327M
††Only available in quantities of 25 as Part Number HW30116
‡Only available in quantities of 50 as Part Number HW07321
Table 5-9. Ribbon Take-up Spindle and Pulley
Item Part Number Description
Qty
1 40050M Kit, Maintenance, Ribbon Take-up 1
2 . Assembly, Bearing Support 1
3 . . Bearing Support
4 30422-002 . . Screw, 6-32 x 0.25 1
5 . . Spring, Compression 0.088 x 0.250 1
6 30438 . . Spring Support 1
7 30112 . . Bearing, Ball 1.125 x 0.500 x 0.312 2
8 . E-Ring External 0.5 x 0.042 1
9 40057 . Shaft, Spindle Media and Ribbon Take-up 1
10 30422-006 . Screw, 6-32 x 0.375 2
11 30073 .Plate, Clutch 2
12 . Washer, Felt 1-1/4 x 19/32 x 3/32 2
13
† . Assembly, Ribbon Spindle 1
14
†† . Spring, Compression 0.720 x 0.610 x 0.625 1
15 ‡ . Screw, 6-32 x 0.18 2
16 30058-2 . Nut, Shoulder 0.50-20 1
17 40490-2 . Hook, 6 inch 1
18 31336M Kit, Maintenance MTU/RTU 1
19 30080-4 .Pulley 1
20 . Clutch, 0.75 x 0.50 x 0.50 1
21 .Spacer 1
N/S ‡‡ Kit, Spindle Felt Pads for all Spindles
‡‡Contains: 1 01889 2oz. Bottle of Silicone Oil
2 30041-1 Washer, Felt 11/4” x 19/32” x 3/32”
2 30041-2 Washer, Felt 21/4” x 19/32” x 3/32”
2 30041-3 Washer, Felt 7/8” x 5/8” x 3/32”
1 30041-4 Washer, Felt 29/32” x 1/2” x 3/32”
1 30041-5 Washer, Felt 7/8” x 13/32” x 3/32”
1 30041-6 Washer, Felt 13/16” x 13/32” x 3/32”
2 30041-7 Washer, Felt 15/8” x 17/32” x 0.093”
1 30042 Spring, Torsion 0.739 x 0.805
Bold = Part available for purchase
Light italic = Part not available for purchase, listed and shown for reference only
