General| Type | Handheld bar code reader |
|---|---|
| Wavelength | 655 nm |
| Sensor type | Laser |
| Scanner type | 1D/2D |
| Tilt reading angle | 0 - 360 ° |
| Pitch reading angle | 0 - 65 ° |
| Light levels (direct sunlight) | 0 - 108000 lx |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E |
| Optical sensor resolution (W x H) | 1280 x 960 pixels |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39 |
| Input voltage | 4.5 - 5.5 V |
| Power source type | RS-232, USB |
| Certification | RoHS EN 50581: 2012 |
| Product color | Black, Grey |
| LED indicators | Yes |
| International Protection (IP) code | IP65 |
| Standard interfaces | Keyboard wedge, RS-232, USB |
| Connectivity technology | Wired |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -30 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| Harmonized System (HS) code | 84716070 |
Weight and Dimensions| Depth | 132 mm |
|---|---|
| Width | 77 mm |
| Height | 185 mm |
| Weight | 304 g |
