Zebra P110 - Controls and Indicators

2P110i & P110m Card Printer User’s Manual 980515-001 Rev. C
Getting Started
Controls and Indicators
Multi-Function LCD Panel
Your printer is equipped with a Multi Function LCD Readout Panel to provide printer status
information. The readout is controlled by the multi-function control button directly below the
viewing window.
The LCD Panel can display the following messages:
Message Mode
Operational
Initializing
Fixed
SELF TEST
Fixed
READY
Fixed
DOWNLOADING DATA
Fixed
MAG ENCODING
Fixed
PRINTING MONO
Fixed
PRINTING CYAN
Fixed (These
messages do not
apply to the P110m
Printer.)
PRINTING YELLOW
PRINTING MAGENTA
PRINTING BLACK
PRINTING OVERLAY
DOWNLOADING FIRMWARE
Fixed
Multi-Function
Control Button
Multi-Function
LCD Panel
