Printer Setup
980515-001 Rev. C P110i & P110m Card Printer User’s Manual 23
Card Output Hopper
1. Raise the printer lid and pull the output hopper down to place it in its functional position.
2. When not using the printer, place the card output hopper back in its closed position to
protect the printer from dust.
Printing a Test Card
With ribbon cartridge and cards loaded, your printer is ready to print. To check the operation of
the printer, you should print a test card.
1. Place the printer power switch in the OFF (0) position.
2. While holding down the Multi Function Button, place the printer power switch in the
ON ( | ) position. The LCD status window will glow blue.
Card
Stack
Card Feeder
Card Feeder Cover
Card
Output
Hopper
To Next Page
