Zebra P110 - Card Dimensions

Technical Specifications
980515-001 Rev. C P110i & P110m Card Printer User’s Manual 43
Card Dimensions
ISO standard dimensions for plain card
ISO standard dimensions for magnetic stripe card
980504-07-01
2.125 ± 0.002in
(53.98 ± 0.050mm)
Radius
0.125in
(3.18mm)
3.375 ± 0.010in
(85.72 ± 0.25mm)
0.009 ~ 0.034in
(0.23 ~ 0.84mm)
980504-07-02
0.623in (15.82mm) min
0~0.115in (2.92mm)
0~0.115 in (2.92 mm)
MAGNETIC STRIPE
0.218in (5.54mm) max
