980584-001 Rev. A Zebra P110i / P110m / P120i Card Printers Service Manual 7
1.3 Specifications
General
• Load-N-Go
TM
drop-in ribbon cartridge
• 16-digit LCD display
• Driver for Windows 2000, Windows XP, Windows Server 2003, and Windows Vista
Color / Monochrome Printing (P110i & P120i)
• Color dye sublimation or monochrome thermal transfer printing
• 30 seconds per card full color single sided (YMCKO)
• 40 seconds per card full color dual sided (YMCKOK) (P120i only)
• 300 dpi (11.8 dots/mm) print resolution
Monochrome Printing (P110m)
• Monochrome thermal transfer printing
• 300 dpi (11.8 dots/mm) print resolution
Bar Code
• Code 39, Code 128 B & C with & without check digit
• 2 of 5 & 2 of 5 Interleaved
• UPC-A, EAN 8, & EAN 13
• PDF-417 2D bar code and other symbologies can be printed via Windows drivers
Cards
• The use of Zebra cards will give the best print quality
• Types: PVC, PVC Composite
• Card width/length: ISO CR-80-ISO 7810, 2.12" (54mm) x 3.38" (86mm)
• Magnetic Stripe-ISO 7811
• Smart Card-ISO 7816
• Card thickness: 30 mil (.76mm) (
± 10%)
• Card feeder capacity: 100 cards (30 mil)
• Card output hopper capacity: 45 cards (30 mil)
Ribbon Cartridges
• The use of Zebra True Colours
®
ribbons will give the best print quality
• Load-N-Go
TM
ribbon cartridge with integrated card-cleaning roller
• i Series technology featuring contact-chip-based ribbon detection (P110i & P120i)
• YMCKO: 200 cards/cartridge (P110i & P120i)
• YMCKOK: 165 cards/cartridge (P120i only)
• Monochrome: 1000 cards/cartridge in black or blue; 850 cards/cartridge white

Zebra P110i Specifications

General

USB 1.1 ports quantity	1
Weight (imperial)	10 lbs
Dimensions (WxDxH)	201 x 328 x 235 mm
Storage temperature (T-T)	23 - 158 °F
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
Power requirements	100 ~ 240 Volts AC, 50 ~ 60 Hz
Certification	FCC Class A CE UL CUL

Weight and Dimensions

Weight	4500 g
