46 P110i User’s Manual 980515-001 Rev. A
Card SenseTM Single Card Feed Mode
Printing a Single Card
Setting Up the Printer Driver
1. Go to Printer Properties
2. Select the Device Settings tab
3. Select Single Feed Properties
4. Select Enable Single Feed Support
5. Click the Apply button.
Printing a Single Card
1. Place the printer power switch in the ON ( | ) position.
2. Insert a single card into the slot at the front of the printer, directly above the card output
hopper. Do not feed more than one card at a time. Printer will take the card.
Important • You can disable Single Feed Support and return to printing cards from the
hopper. You do not have to remove the components of the Single Card Feed Kit in order to
operate in normal mode.
INSERT CARD
