P4T Vehicle Cradle Installation Guide
Required for Installation
An electrical drill, 1/4”(6 mm) drill bit•
Common hand tools.•
#10-32 or 10-24 Bolts with self-locking (ESN) nuts and appro-•
priate mounting hardware for securing the Vehicle Cradle
Note: Use of appropriate hardware used to secure the Vehicle Cradle to the
vehicle is the responsibility of the installer
Reference
P4T User’s Guide•
Contents of the Package
The P4T Vehicle Cradle Assembly•
One of two power input cables: either (1) an unterminated •
cable with an integrated fuse holder, or (2) a cable terminated
with a cigarette lighter adapter.
Hardware for routing and securing the input power cable.•
This Guide•
Installation
Introduction to Installation
The P4T Vehicle Cradle allows you to mount a P4T printer into vir-
tually any vehicle with an electrical system voltage 12 VDC. The
installation kit provided with the Cradle includes an input power ca-
ble which, when connected to the vehicle’s electrical system, pro-
vides power to run the Printer and charge its battery.
The input power cable is wired to the vehicle’s battery power sys-
tem indirectly through a power take-off point. One version of the
Vehicle Cradle supplies an input power cable that can be plugged
into an automotive vehicle’s cigarette lighter.
CAUTION: Under no circumstances should this equipment be attached di-
rectly to the vehicle’s battery without a proper fuse.
Since each situation or equipment type may pose unique require-
ments, mounting hardware selection and mechanical installation
shall be the responsibility of the installer. Zebra recommends us-
ing self-locking (ESN) nuts, bolts, and/or lock washers for installing
the mount. The Cradle is secured with #10-32 or #10-24 mounting
hardware (4 places).
Note: Hardware used to secure the Vehicle Cradle to the vehicle is not
supplied in the installation kit.
Your tasks are to:
Mechanically prepare and install the P4T Vehicle Cradle•
