Zebra R110Xi/R170Xi
Specifications at a Glance*
STANDARD FEATURES
Fully integrated ThingMagic
®
UHF RFID
reader/encoder for transponder types:
EPC Class 1 Gen 2
ISO18000-6B, ISO18000-6C
RFID processes optimized for fastest label
throughput
RFID ZPL commands allow ease of RFID setup
with maximum flexibility
Program position allows users to place
transponders virtually anywhere within a smart
label
RFID calibration feature automatically selects the
program position for optimal transponder
placement
RFID counters keep track of the good and
unusable labels
Variable RFID power settings for both read and
write allows maximum flexibility for printing
small labels
Full-function front panel and multilingual back-lit
LCD display with user-programmable password
protection
Multi-level Element Energy Equalizer™ (E
3®
) for
superior print quality
Thermal transfer and thermal direct printing of
bar codes, text, and graphics
32 bit 133 MHz RISC processor
Clear media side door—easy monitoring of
supplies usage without opening the printer
systems
Zebra printer driver for Windows
®
3.X and
95/98/NT/2000/XP/2003 operating systems
Internal real-time clock
Advanced label/media counters
Auto calibration—printer calibrates when
printer is turned on or when printhead is closed
with approximately two labels
Early Warning Systems for low label, low
ribbon, and clean printhead alerts
Unicode™compliant
XML–Enabled–printing—direct-connect
integration for bar code label printing;
eliminates license fees and print server
hardware and lowers customization and
programming costs
PRINTER SPECIFICATIONS
Memory
PCMCIA or CompactFlash
®
(up to 256 MB
memory each). (CF card not supported with
ZebraNet Wireless Plus print server.)
Print length
Maximum non-continuous: 39" (991 mm) with
standard memory
Media Sensors
Dual media sensors: transmissive and
reflective
MEDIA CHARACTERISTICS–SMART
LABELS
Maximum label and liner length
39"/991 mm with standard memory
Maximum roll outside diameter
8.0" (203 mm)
Core diameter
3" (76 mm) core
Media thickness
.003" (.076 mm) to .012" (.305 mm)
Media types
Continuous, die-cut, black mark
For optimum print quality and performance,
use genuine Zebra™ supplies
RIBBON CHARACTERISTICS
Outside diameter
3.2" (81.3 mm)
Standard length
1476' (450 m) or 984' (300 m); provides
3:1 & 2:1 media roll to ribbon ratios
Ratio
Ribbon is recommended to be at least as wide
as media.
Ribbon setup
Ribbon wound coated side out
Core I.D.
1.0" (25.4 mm)
OPERATING CHARACTERISTICS
Environmental
Operating temperature:
Thermal transfer = 41º F/5º C to 104º F/40º C
Thermal direct = 32º F/0º C to 104º F/40º C
Storage temperature: -40º F/-40º C to
140º F/60º C
Operating humidity: 20% to 85%
non-condensing R.H.
Storage humidity: 5% to 85%
non-condensing R.H.
Electrical
Universal power supply with power-factor
correction 90-264 VAC, 48-62 Hz
Agency approvals
Bi-National UL 60950 3rd edition/CSA
CAN/CSA-C22.2 No. 60950-00 Third Edition;
FCC Part 15.107 & 15.109 Class B; FCC Part
15.247; Canadian ICES-003, Class B;
IC RSS-210
Zebra also has country-specific versions
available. Contact your local representative
for more information.
Printer name
R110Xi; R170Xi
Printer model
110Xilll; 170Xilll
RELATED PRODUCTS
Options and Accessories
Additional fonts
Applicator interface
Media supply spindle
Media rewind spindle
PCMCIA or CompactFlash (CF) card (not
supported with ZebraNet Wireless Plus)
COMMUNICATIONS AND
INTERFACE CAPABILITIES
High-speed serial interface
High-speed bi-directional, IEEE 1284-1994
parallel interface
USB 2.0 port
FONTS
/GRAPHICS/SYMBOLOGIES
Fonts and Character Sets
Standard fonts: 7 bitmapped, 1 smooth
scalable (CG Triumvirate-Bold Condensed)
Contains UFST
®
from Monotype Imaging, Inc.
Sets: IBM
®
Code Page 850 International
character set
Graphic Features
Supports user defined fonts and
graphics—including custom logos
Bar Code Symbologies
Linear Bar Codes: Code 11, Code 39, Code 93,
Code 128 with subsets A/B/C and UCC Case
C Codes, ISBT-128, UPC-A, UPC-E, EAN-8,
EAN-13, UPC and EAN 2 or 5 digit exten-
sions, Plessey, Postnet, Standard 2-of-5,
Industrial 2-of-5, Interleaved 2-of-5, Logmars,
MSI, Codabar, and Planet Code
2-Dimensional: Codablock, PDF417, Code 49,
Data Matrix, MaxiCode, QR Code,
MicroPDF417, TLC 39, GS1 DataBar (RSS),
Aztec
