Zebra RW SERIES User Manual

48
RW Series User Guide
• Remove the Docking Connector Cover from the bottom
of the printer, and retain it for future use. (Refer to Figure
22.)
• Place the bottom of the printer over the two pins in the
Cradle.
• Rock the top of the Printer into the Cradle and press firm-
ly until it latches in place.
• Ensure the Cradle power and charge indicators are lit and
turn the printer on.
If the charge indicator does not light up, unlatch the printer from the
Vehicle Cradle, lift it clear from the Cradle and re-seat it.
Refer to the Vehicle Cradle Installation Guide for more complete
information on the power and charge indicators
You can load media (including media from an external sup-
ply) and perform cleaning operations normally when the
RW 420 Printer is installed in the Cradle .
