Page 7-12
44868L
PRINTER MODEL: STRIPE
Drive System
PART NUMBER DESCRIPTION QUANTITY
44019 Idler Shaft
1
44022 Platen Pulley
1
44023-0M Stepper Motor (S-500) (8 Dot/mm printer Non-
Peel)
1
44023-1M Stepper Motor (S-300)
1
44023-6M Stepper Motor (S-500) (6 Dot/mm printer Non-
Peel)
1
44025 Pulley 20T
1
44053 Screw, M3.5 w/SEMS
1
44055 Nut, M5 Hex
1
44100 Set Screw, Shaft Collar & Bevel Gear
1
44172-2 Ground Chain Assy. (1 1/8")
1
44177 Tearplate Ground Strap
1
44356 Washer, Flat
1
45189-6 S-500 Drive Belt (8 Dot/mm) (165 T)
1
45189-8 S-300 Drive Belt (160 T)
1
45189-10 S-500 Drive Belt (6 Dot/mm) (170 T)
1
** For Peel-Off Option Parts refer to Pages 8-20 through 8-23
Drawings and Parts Lists Stripe Maintenance Manual: Volume 1
