Page 7-14
44868L
PRINTER MODEL: STRIPE
Platen and Power Supply
PART NUMBER DESCRIPTION QUANTITY
30260 Washer, Wave .250
6
30261 Washer, Flat .250
2
44004 Power Supply Base
1
44013 Bearing, Platen
2
44014 Rubber Bumper
6
44020 Roller, Platen
1
44114 Screw, M4.2 x 1.41 x 8 Hi-Lo Hex/Phillips
2
44187 Screw, 6-20 2.0"
2
44282 Tear-Off Plate
1
44484 Screw, M4.2 x 1.41 x 25 Hi-Lo Hex
1
44523 Ground Cable, 12" (also part of Power
Supply)
1
44542M Power Supply Assembly (S-500)
(Superceded by 44646M)
1
44644M Power Supply Assembly (S-300)
1
44646M Power Supply Assembly (S-500)
(Supercedes 44542M)
1
Drawings and Parts Lists Stripe Maintenance Manual: Volume 1
