Zebra Stripe - Printhead Assembly

Page 7-16
44868L
PRINTER MODEL: STRIPE
Printhead Assembly
PART NUMBER DESCRIPTION QUANTITY
01159 Washer, Lock, Star
1
10401 Screw, M3 x .5 x 4
5
10403 Screw, M3 x .5 x 6
3
30956 Washer, Flat
2
40193 Washer, Flat
2
44000M Printhead Element 8 Dot/mm (104mm)
1
44018 Ribbon Strip Plate
1
44032 Head Bracket (Includes Shaft)
1
44039 Head Pivot Arm (Includes Shaft & Bearing)
1
44054 Screw, M3.5 w/SEMS
2
44100 Set Screw, Shaft Collar & Bevel Gear
2
44118 Shaft Collar
1
44123 Ground Strap
1
44125 Printhead Support Bracket
1
44200M Printhead Element 6 Dot/mm (104 mm)
1
44520 Cable Assembly
1
44940 Head Mounting Bracket
1
Drawings and Parts Lists Stripe Maintenance Manual: Volume 1
