Page 7-20
44868L
PRINTER MODEL: STRIPE
Peel-Off Option Rear View
PART NUMBER REF. DESCRIPTION QUANTITY
01159 Washer, Lock, Star
1
01882 Screw, 4-40 Phillips
4
44023-2M Stepper Motor (S-500) (8 Dot/mm printer w/Peel)
1
44114 Screw, M4.2 x 1.41 x 8 Hi-Lo Hex/Phillips
1
44172-1 Ground Chain Assy. (1 3/4")
1
44191 Ground Chain Assy. (5 1/16")
1
44216 Screw, M4.2 x 1.41 x 13 Hi-Lo Hex
1
44264M
F
Carrier Bearing Assembly Kit
1
44282 Tear-Off Plate
1
44283 Spacer, Tear-Off Plate
2
44331 Drive Belt (Peel-Off Option Only)
1
44341M
E
Power Roller Kit
1
44358M
C
Media Take-Up Idler Kit
1
44359M
B
Upper Idler Kit
1
44368M
D
Carrier Idler Kit
1
44371M
G
Roller Idler Kit
1
44383 Ground Cable (6")
2
44387 Screw, M3.5 w/SEMS
1
44536M
A
Sensor Assembly Kit, Take Label
1
44665 Switch Assy, Full Roll
1
45189-7 Media Rewind Belt
1
Drawings and Parts Lists Stripe Maintenance Manual: Volume 1
