FORMAT PRINTING TEST FUNCTION
1 20 at Speed D Left Ribbon Wrinkle
2 20 at Speed D Right Ribbon Wrinkle
3 20 at Speed D Bar Code Wrinkle Test (Code-39)
8 20 at Speed A Left Ribbon Wrinkle Test
9 20 at Speed A Right Ribbon Wrinkle Test
10 20 at Speed A Bar Code Wrinkle Test (Code-39)
4 10 at Speed D Useable Area
5 10 at Speed D Head Temp Test
6 10 at Speed D Upper Smear Test
7 10 at Speed D Lower Smear Test
11 10 at Speed A Useable Area Test
12 10 at Speed A Head Temp Test Test
13 10 at Speed A Upper Smear Test
14 10 at Speed A Lower Smear Test
Figure 3.7 Test, Formats 1 and 8
Printer Diagnostics Stripe Maintenance Manual: Volume 1
Page 3-8 44868L
