Zebra Stripe - Printer Specifications

Printer Specifications
Printing Considerations
Printing Specifications Stripe S-300
Printer
Stripe S-500
Printer
Stripe S-500 Printer
with Optional 6 Dots
per mm Printhead
Resolution 203.2 dots per inch (8 dots per mm) 152.4 dots per inch
(6 dots per mm)
Dot size (square) 0.00492" (0.125 mm) 0.00656" (0.167 mm)
Maximum print width 4.09" (104 mm)
Print
length
Minimum 0.00492" (0.125 mm) 0.00656" (0.167 mm)
Maximum Standard
memory
6" (152 mm) 15" (381 mm) 26" (660 mm)
With
additional
memory
18" (457 mm)
(256k expansion)
39" (991 mm)
(512k expansion)
39" (991 mm)
(512k expansion)
Bar code modulus (“X”) dimension 5 mil to 55 mil 6.6 mil to 72 mil
Programmable constant printing
speeds
2" (50.8 mm) 2" ( 50.8 mm)
3" ( 76.2 mm)
4" (101.6 mm)
5" (127.0 mm)
6" (152.4 mm)
Thin film printhead with Energy Control
Media Handling
• Tear-Off mode: Labels produced in strips
• Peel-Off mode*: Labels dispensed and peeled from the liner
• Cutter mode*: Labels are printed and individually cut
• Rewind mode*: Labels externally rewound (requires optional media
rewinder - not available from Zebra Technologies Corporation)
* Options
The Zebra Stripe
®
System Stripe Maintenance Manual: Volume 1
Page 2-2 44868L
