Page 7-6
44868L
PRINTER MODEL: STRIPE
Ribbon and Media Supply
PART NUMBER DESCRIPTION QUANTITY
10432 Screw, M4
1
30251 Washer, Flat
4
44043M Ribbon Tension Motor Assy.
(Includes 44172-1, 44481)
1
44046-2 Gear, Bevel
1
44052M Ribbon Take-Up Spindle Assy. (Non- Peel-
Off)
1
44052-2M Ribbon Take-Up Spindle Assy. (Peel-Off
Option)
1
44066M Media Supply Edge Guide Assy.
1
44067 Thumb Screw
1
44068 Edge Guide, Media
1
44069 Bracket, Media
1
44084 Washer, Flat
4
44100 Set Screw, Shaft Collar & Bevel Gear
6
44114 Screw, M4.2 x 1.41 x 8 Hi-Lo Hex/Phillips
2
44118 Shaft Collar
1
44174 Chain Clip
1
44198M Cable, Ribbon Motor (also part of 44043M)
1
44278 Ground Chain Assy. (1 3/4")
1
44356 Flat Washer
1
44481 Ground Chain Assy. (1 3/8")
1
44912M Dual Torque Ribbon Supply Spindle kit
1
Drawings and Parts Lists Stripe Maintenance Manual: Volume 1
