Page 7-8
44868L
PRINTER MODEL: STRIPE
Toggle and Printhead Assembly
PART NUMBER DESCRIPTION QUANTITY
44030 Print Mechanism Assy. (w/o Printhead)
1
44054 Screw, M3.5 w/SEMS
1
44093 Spring, Head Open
1
44124 Support, Head Pivot
1
44216 Screw, M4.2 x 1.41 x 13 Hi-Lo Hex
2
44329M Toggle Assembly
1
44459 Shaft Collar
2
44466 Ground Strap
1
Drawings and Parts Lists Stripe Maintenance Manual: Volume 1
