Zebra TLP 2824 Plus User Manual

Table of Contents
Zebra Printer Packing List ......................................................................................... Page 2
Getting to Know Your Printer...................................................................................... Page 3
Loading Labels........................................................................................................... Page 4
Loading Ribbon.......................................................................................................... Page 5-6
Perform AutoSense Adjustment................................................................................. Page 7
Setting Up New System ............................................................................................. Page8
Printing a Label .......................................................................................................... Page 9
Trouble Shooting ........................................................................................................ Page 10
Label Form descriptions............................................................................................. Page 11-14
Samples for Vertical Labels........................................................................................ Pages 15-18
Samples for Horizontal Labels ................................................................................... Pages 19-22
1

Zebra TLP 2824 Plus Specifications

General

Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Core diameter	25.4 mm
Media thickness	0.08 - 0.18 mm
Maximum media length	991 mm
Maximum roll diameter	127 mm
Media thickness (imperial)	0.003 - 0.007 \
Maximum media length (imperial)	39 \
USB 1.1 ports quantity	1
Connectivity technology	Wired
Dimensions (WxDxH)	135 x 241 x 178 mm
Flash memory	4 MB
Certification	-FCC, -VCCI, -C-TICK, -UL, -NOM, -CE, -IRAM, -AAMI.
Internal memory	8 MB
Built-in barcodes	Code 39, Code 49, Code 93, MaxiCode, PDF417, Postnet, QR Code, UPC-A, UPC-E
Page description languages	EPL
Storage temperature (T-T)	-40 - 140 °F
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power requirements	100 - 240 VAC, 50 - 60 Hz
Package weight	2800 g

Weight and Dimensions

Weight	1600 g
