Zebra Desktop Series 3844-Z Product Guide
3844-Z Product Guide Rev. 1
August 9, 2005
11
• Ribbon Capacity: The capacity of the ribbon roll is to be sufficient enough to completely print one
roll of media. (1 roll of 5”OD media is the full ribbon capacity)
• Core ID: 0.5” (12.7 mm).
• Ribbon OD: 1.3” (33 mm).
• Ribbon Length: 244' (74m) using 0.000328" ribbon thickness
• Ribbon Type: Wax, wax/resin and resin.
Media Specifications
NOTE: For optimum print quality and printer performance, use of Zebra genuine supplies is recommended.
• Media Width - 1.00” (25.4mm) – 4.25” (108mm)
• Label Length:
Minimum - 0.38” (9.7mm)
Minimum with label taken sensor used - 0.50” (12.7mm)
Minimum with cutter – 1.0” (25.4mm)
Maximum with standard memory - 39" (990mm)
• Core Inner Diameter: 1.00” (25.4mm), 1.5" (38mm)
• Max Roll Diameter: 5.00” (127mm)
• Media Thickness: 0.003” (0.075mm) - 0.007” (0.18mm)
• Media Sensing: gap, black line, notch
• Media Types - Roll-fed or fan-fold, die cut or continuous direct thermal labels with or without black mark,
tag stock
Calibration Procedure
• The 3844-Z is equipped with a standard auto-calibration feature that initiates automatically during
start-up of the printer - utilizing two to four labels to calibrate for efficient operation and less waste.
The printer will also save the new settings in memory until the next calibration is performed.
• A manual calibration procedure can also be performed, if required. Consult your User’s Guide for
more details on the specific manual calibration steps.
Font Specifications: 300 dpi (12 dots/mm)
Fonts Matrix
(in dots)
(H x W)
Type† Minimum Char.
Size
(H x W)
Maximum
C.P.I.
A 9 x 5 U-L-D .030" x .020" 50.8
B 11 x 7 U .037" x .030" 33.8
C,D 18 x 10 U-L-D .060" x .040" 25.4
E 41 x 20 OCR-B .138" x .085" 11.5
F 26 x 13 U-L-D .085" x .053" 19.06
G 60 x 40 U-L-D .200" x .160" 6.36
H 30 x 19 OCR-A .100" x .098" 10.02
GS 24 x 24 SYMBOL .80" x .80" 12.7
P-V U-L-D
Ø 15 x 12 U-L-D Scalable (Smooth)
Font
• Character Fonts: Standard bitmapped Zebra fonts: A, B, C, D, E (OCR-B), F, G, H, (OCR-A), GS, P,
Q, R, S, T, U, V & Ø Smooth font (CG Triumvirate
™
Bold Condensed).
• Character Sets: IBM
®
Code Page 850 International characters & graphic symbols
• Supports user defined fonts and graphics – including custom logos
• Bitmap fonts are expandable up to 10 times, height and width independent. Fonts E and H (OCR-B
and OCR-A), however, are not considered in spec when expanded.
• Smooth scalable font Ø (CG Triumvirate
™
Bold Condensed) is expandable dot-by-dot, height and
width independent, while maintaining edges to a max. 1500 x 1500 dots.
• IBM
®
Code Page 850 International Characters available in fonts A,B,D,E,F,G and Ø through software
control.
Bar Code Symbologies & Specifications
• Bar code ratios: 2:1 (non-rotated) and 3:1
