4 Z4Mplus and Z6Mplus Maintenance Manual 13358L Rev. 1 11/17/03
Section 1 System Description
Table 1-1. Font Matrix for 8 dot/mm (203 dpi) Printheads
Font Matrix Type* Character Size
Height Width
Baseline
Dots
Inter-
Character
Gap
Cell
Width
Font Matrix
Inches Millimeters
Height Width
Char/
Inch
Height Width
Char/
mm
A 9 5 7 1 6 U-L-D 0.044 0.030 33.87 1.13 0.75 1.33
B 11 7 11 2 9 U 0.054 0.044 22.58 1.38 1.13 0.89
C,D 18 10 14 2 12 U-L-D 0.089 0.059 16.93 2.25 1.50 0.67
E 28 15 23 5 20 OCR-B 0.138 0.098 10.16 3.50 2.50 0.40
F 26 13 21 3 16 U-L-D 0.128 0.079 12.70 3.25 2.00 0.50
G 60 40 48 8 48 U-L-D 0.295 0.236 4.23 7.50 6.00 0.17
H 21 13 21 6 19 OCR-A 0.103 0.094 10.69 2.63 2.38 0.42
GS 24 24 24 2 26 SYMBOL 0.118 0.128 7.82 3.00 3.25 0.31
P 20 18 N/A N/A N/A U-L-D 0.098 0.089 N/A 2.50 2.25 N/A
Q 28 24 N/A N/A N/A U-L-D 0.138 0.118 N/A 3.50 3.00 N/A
R 35 31 N/A N/A N/A U-L-D 0.172 0.153 N/A 4.38 3.88 N/A
S 40 35 N/A N/A N/A U-L-D 0.197 0.172 N/A 5.00 4.38 N/A
T 48 42 N/A N/A N/A U-L-D 0.236 0.207 N/A 6.00 5.25 N/A
U 59 53 N/A N/A N/A U-L-D 0.290 0.261 N/A 7.38 6.63 N/A
V 80 71 N/A N/A N/A U-L-D 0.394 0.349 N/A 10.00 8.88 N/A
0 Default: 15 x 12 U-L-D Scalable
*U = Uppercase, L = Lowercase, D = Descenders
Table 1-2. Font Matrix for 12 dot/mm (300 dpi) Printheads
Font Matrix Type* Character Size
Height Width
Baseline
Dots
Inter-Character
Gap
Cell
Width
Font Matrix
Inches Millimeters
Height Width
Char/
Inch
Height Width
Char/
mm
A 9 5 7 1 6 U-L-D 0.030 0.020 50.00 0.76 0.51 1.97
B 11 7 11 2 9 U 0.037 0.030 33.33 0.93 0.76 1.31
C,D 18 10 14 2 12 U-L-D 0.060 0.040 25.00 1.52 1.02 0.98
E 41 20 32 6 26 OCR-B 0.137 0.087 11.54 3.47 2.20 0.45
F 26 13 21 3 16 U-L-D 0.087 0.053 18.75 2.20 1.35 0.74
G 60 40 48 8 48 U-L-D 0.200 0.160 6.25 5.08 4.06 0.25
H 30 19 30 9 28 OCR-A 0.100 0.093 10.71 2.54 2.37 0.42
GS 24 24 24 2 26 SYMBOL 0.080 0.087 11.54 2.03 2.20 0.45
P 20 18 N/A N/A N/A U-L-D 0.067 0.060 N/A 1.69 1.52 N/A
Q 28 24 N/A N/A N/A U-L-D 0.093 0.080 N/A 2.37 2.03 N/A
R 35 31 N/A N/A N/A U-L-D 0.117 0.103 N/A 2.96 2.62 N/A
S 40 35 N/A N/A N/A U-L-D 0.133 0.117 N/A 3.39 2.96 N/A
T 48 42 N/A N/A N/A U-L-D 0.160 0.140 N/A 4.06 3.56 N/A
U 59 53 N/A N/A N/A U-L-D 0.197 0.177 N/A 5.00 4.49 N/A
V 80 71 N/A N/A N/A U-L-D 0.267 0.237 N/A 6.77 6.01 N/A
0 Default: 15 x 12 U-L-D Scalable
*U = Uppercase, L = Lowercase, D = Descenders
