Zebra ZXP 7 series User Manual

2: Installation and Setup
Installing the Dual Cleaning Cartridge
P1036101-001 Zebra ZXP Series 7 Card Printer User’s Manual 13
Installing the Dual Cleaning Cartridge
The Dual Cleaning Cartridge cleans the cards entering the Printer from the Feeder Cartridge.
The cartridge consists of a cartridge frame and two adhesive rollers.
Step 1. Locate the cartridge frame and the two adhesive rollers.
Step 2. Insert the adhesive rollers into the cartridge frame.
Step 3. Peel the protective wrapper from the adhesive rollers to expose the sticky surface.
Do not touch the sticky surface.
Step 4. The Dual Cleaning Cartridge is ready to use.

Zebra ZXP 7 series Specifications

General

Print Resolution	300 dpi
Connectivity	USB 2.0, Ethernet
Memory	64 MB standard
Print Technology	Dye-sublimation thermal transfer
Card Capacity	200 cards input hopper, 100 cards output hopper
Card Sizes	CR-80 ISO 7810, 2.12" (54 mm) x 3.38" (86 mm)
Power Requirements	100-240 VAC, 50-60 Hz
