Introduction
Components
P1013372-001 Rev. A Zebra ZXP Series 8 Card Printer with Laminator 3
Front View, Printer Cover Open
The following figure shows components of the Printer.
Transfer Film
Transfer Station
Print Ribbon
Printhead
(Under Print
Ribbon)
Card
Cleaning
Cartridge
Card
Cleaning
Roller
Reject Bin
(Under Feed Tray)
Mag Encoder and/or Smart Card
Options (If Installed); Components
Under This Cover
