4 Zebra ZXP Series 8 Card Printer with Laminator P1013372-001 Rev. A
Introduction
Components
Front View, Laminator Cover Open
The following figure shows components of the Laminator.
Heater
Upper Laminate Cassette
(single-sided and dual-sided laminators)
Lower Laminate Cassette
(dual-sided laminator only)
Lower Laminate Cassette Latch
(dual-sided laminator only)
Upper Laminate Cassette Latch
(single-sided and dual-sided laminators)
Output
Hopper
Manual Advance Tool
Enclosure
Lock
(optional)
