Zebra ZXP Series 7 User Manual

2: Installation and Setup
Unpacking the Printer
P1036101-002 Zebra ZXP Series 7 Card Printer User’s Manual 7
Step 5. Lift the Printer out of the carton by holding it with both hands.
Step 6. Place the Printer in a location that meets the following requirements:
• A reasonably dust-free and dirt-free environment.
• Flat surface at least 40 in (1016 mm) x 12 in (305 mm) that can support the
weight of the Printer; additional space preferred. Allow a 4-inch clearance,
minimum, on all sides.
• Vertical clearance at least 32 in (813 mm).
• Temperature within the range of 59° to 95°F (15° to 35°C).
• Relative humidity 20 to 80% inclusive, non-condensing.
• Auto-switching single-phase AC Power, 90V~264V AC, 47-63Hz (50-60Hz
nominal); see Electrical specifications on page 157 for power consumption.
Step 7. Remove the Printer from the protective bag.
Caution • The Printer with Laminator weighs approximately 17.9 kg (39.5 lbs). Use two
people to lift it out of the shipping carton.
Important • When moving the printer from storage (23º F/-5º C to 158º F/70º C) to the
operating area (59º F/15º C to 95º F/35º C), allow time to acclimate prior to operation.

Zebra ZXP Series 7 Specifications

General

Display	LCD
Lamination	Yes
Certification	FCC A, ENERGY STAR
Product color	Black
Total input capacity	200 sheets
Display number of characters	21
Card types	PVC, PVC Composite
Print technology	Dye-sublimation/Thermal transfer
Maximum resolution	300 DPI
Print speed (color)	300 card/h
Print speed (monochrome)	1375 card/h
Printing media thickness	250 - 1270 µm
Duplex print speed (color)	225 card/h
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
AC input voltage	90 - 264 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Dimensions (WxDxH)	964 x 277 x 306 mm
