Zebra ZXP Series 7 User Manual

8 Zebra ZXP Series 7 Card Printer User’s Manual P1036101-002
2: Installation and Setup
Loading Cards
Loading Cards
Step 1. Remove the wrapping from the card stack.
Step 2. Holding the card stack by the sides (do not touch the print surfaces), hold it
vertically against a flat surface such as a desktop. If the stack is too thick for your
hand to hold it comfortably, use about half a stack at a time.
Step 3. Push the stack back and forth to an angle of about 45
° from vertical, so as to separate
all of the cards.
Step 4. Restore the card stack to its original squared-off condition.
Caution • DO NOT bend cards or touch print surfaces as this can reduce print quality.
The surface of the cards must remain clean and dust free. Always store cards in an
enclosed container. Ideally, use cards as soon as possible after unwrapping.
Note • Static charges and edge burrs from the card die-cutting process can render individual
cards stuck together with significant adhesion force. These cards must be physically
separated from each other before inserting into the feeder; if not separated, feeding or
printing problems may occur.

Zebra ZXP Series 7 Specifications

General

Display	LCD
Lamination	Yes
Certification	FCC A, ENERGY STAR
Product color	Black
Total input capacity	200 sheets
Display number of characters	21
Card types	PVC, PVC Composite
Print technology	Dye-sublimation/Thermal transfer
Maximum resolution	300 DPI
Print speed (color)	300 card/h
Print speed (monochrome)	1375 card/h
Printing media thickness	250 - 1270 µm
Duplex print speed (color)	225 card/h
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
AC input voltage	90 - 264 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Dimensions (WxDxH)	964 x 277 x 306 mm
