Zebra ZXP Series 7 User Manual

2: Installation and Setup
Loading Cards
P1036101-002 Zebra ZXP Series 7 Card Printer User’s Manual 9
Step 5. Open the Feeder Cartridge Door, and slide the Card Stack Pusher all the way to the
right, until it locks in place.
Step 6. Place the card stack in the Feeder Cartridge in the correct orientation shown below.
For Cards with a Barcode, see Appendix F for details.
Step 7. For optimum performance, ensure that the cards are fully seated; then close the
Feeder Cartridge Door.

Zebra ZXP Series 7 Specifications

General

Display	LCD
Lamination	Yes
Certification	FCC A, ENERGY STAR
Product color	Black
Total input capacity	200 sheets
Display number of characters	21
Card types	PVC, PVC Composite
Print technology	Dye-sublimation/Thermal transfer
Maximum resolution	300 DPI
Print speed (color)	300 card/h
Print speed (monochrome)	1375 card/h
Printing media thickness	250 - 1270 µm
Duplex print speed (color)	225 card/h
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
AC input voltage	90 - 264 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Dimensions (WxDxH)	964 x 277 x 306 mm
