Parameters
Model DSO1C81 Coupling AC/DC
Channels 1 AUTO Support
Screen size 2.8inch Measurement
14 types
Bandwidth 80Mhz DC Offest ±3%
Sampling rate 250MSa/s Freq_meter 10Hz~30Mhz
Equivalent sample 500M/s Screenshot Support
Storage depth
480Kbit(60Kpts) Frequency ±0.01%
Rise time <4ns Pulse counter Support
Impedance 1MΩ FFT Support
Time base 5ns – 10s Generator vol 3V
Ver sensitivity
10mV/div-10V/div Generator freq
5MHz(sin) /1MHz(other)
Max voltae 40V（x1）
220V（x10）
Shell size hight*width* thickness
12 *8 *3.2cm
Trigger mode Auto/Normal/Single Language CN/EN
Trigger type rise/fall Charger TYPE-C / 5V
Display mode YT / Roll Built-in power
lithium battery
Persistence None/1s / ∞ Weight ~156g
