General Information
Humphrey Field Analyzer 3 Service Manual 11 2660021151225 A
CAUTION: Allow the lamp to cool completely
(approximately five minutes) before handling it.
CAUTION: Do NOT touch the two disk-shaped filters.
5. Remove the connector cable by pulling its connector straight
upward. Then use a screwdriver to loosen the screw.
Figure 4. Connector Removal
6. Now, slide the wishbone-shaped plate that holds the lamp
assembly in place away from you.
Figure 5.
