27
11.0 PURGE CHARTS
0
10
20
30
40
50
60
70
80
90
0 10203040506070
Purge Air Flow - SCFM
Purge Meter Setting - psig
Dryer Model: 400ZPB
Purge Pressure Setting: 45 psig @ 65 SCFM
Purge Orifi ce: 5/16”
0
10
20
30
40
50
60
70
80
90
100
110
120
130
0 10203040506070
Purge Air Flow - SCFM
Purge Meter Setting - psig
Dryer Model: 500ZPB
Purge Pressure Setting: 35 psig @ 81 SCFM
Purge Orifi ce: 3/8”
0
10
20
30
40
50
60
70
80
90
100
110
120
130
0 10203040506070
Purge Air Flow - SCFM
Purge Meter Setting - psig
Dryer Model: 600ZPB
Purge Pressure Setting: 41 psig @ 93 SCFM
Purge Orifi ce: 3/8”
