ZEKS Eclipse
TM
90-5,000ZPB Desiccant Dryers
www.zeks.com
66
15.0 SPARE PARTS
NOTE 1: Refer to the Desiccant Fill Chart in this Technical Manual: SECTION 9, MAINTENANCE AND SYSTEM CHECK
SPARES: Quantity recommended be kept on-hand for maintenance or repair.
CLASS 1: Minimum quantity retained - Where interruptions in service are acceptable.
CLASS 2: Average quantity retained - Where some interruptions in service are acceptable.
CLASS 3: Maximum quantity retained - Where interruptions in service are unacceptable.
DRYER MODEL SPARES
P&ID Reference DESCRIPTION 800ZPB 1000ZPB 1200ZPB 1500ZPB QTY/UNIT 1 2 3
MI-4 BLUE MOISTURE INDICATOR (BMI) 705001-SP 705001-SP 705001-SP 705001-SP 1
DESICCANT NOTE 1 NOTE 1 NOTE 1 NOTE 1 NOTE 1
DISPLAY BOARD, PANEL 633653 633653 633653 633653 1
DRYER CONTROLLER, NEMA 4 1
Provide dryer Model and Serial Number 47606394001 47606394001 47606394001 47606394001
to ensure correct confi guration.
FR-1 ELEMENT, CNTRL AIR FILTER/REG 104422 104422 104422 104422 1 1 1 2
FLT-2 ELEMENT, PREFILTER - HIGH EFF EC920H EC1080H EC1350H EC1600H 1 1 1 2
FLT-3 ELEMENT, AFTERFILTER - PARTIC EC920G EC1080G EC1350G EC1600G 1 1 1 2
DPI-2, 3 GAUGE, DIFF PRESSURE, FILTER 634658 634658 634658 634658 2
PI-1, 2, 3 GAUGE, PURGE/TOWER PRESS 631324 631324 631324 631324 3
DR-2, 3 INTERNAL DRAIN, FILTER 634668 634668 634668 634668 2
EXH-1, 2 MUFFLER, PURGE 680711 (2) 680711 (2) 680711 (2) 680455 (2) (Qty) (Qty) (Qty) (Qty)
– OVERLAY, CONTROLLER 634083 634083 634083 634083 1
– POWER SUPPLY 47587161001 47587161001 47587161001 47587161001 1 1 1 1
FX-1A, 2A RETAINER, DES SCREEN UPPER 725139-SP 725139-SP 725139-SP 725140-SP 2
FX-1B, 2B RETAINER, DES SCREEN LOWER 725139-SP 725139-SP 725139-SP 725140-SP 2
FV-1A, 2A VALVE, TOWER INLET 47633579001 47633579001 47633579001 47633580001 2
FV-1B, 2B VALVE, TOWER PURGE 47590669001 47590669001 47590669001 47590672001 2
HCV-1 VALVE, PURGE FLOW METERING 680712 680712 680712 680712 1
HCV-2, 3, 4 VALVE, CNTRL AIR, SHUTOFF/BLEED 681621 681621 681621 681621 3
FV-1P, 2P VALVE, CHECK, TOWER PURGE 683983 683983 683983 683983 2
FV-1C, 2C VALVE, CHECK, TOWER OUTLET 632794 632794 632794 632794 2
PSV-1, 2 VALVE, SAFETY/RELIEF, TOWER 680896 680896 680896 680896 2
FV-4A, 4B, 4C, 4D VALVE, SOLENOID, CONTROL AIR 47606405001 47606405001 47606405001 47606405001 4
