15.0 SPARE PARTS
NOTE 1: Refer to the Desiccant Fill Chart in this Technical Manual: SECTION 9, MAINTENANCE AND SYSTEM CHECK
SPARES: Quantity recommended be kept on-hand for maintenance or repair.
CLASS 1: Minimum quantity retained - Where interruptions in service are acceptable.
CLASS 2: Average quantity retained - Where some interruptions in service are acceptable.
CLASS 3: Maximum quantity retained - Where interruptions in service are unacceptable.
DRYER MODEL SPARES
P&ID Reference DESCRIPTION 1800ZPB 2100ZPB 2700ZPB 3300ZPB 4000ZPB 5000ZPB QTY/UNIT 1 2 3
MI-4 BLUE MOISTURE INDICATOR (BMI) 705001-SP 705001-SP 705001-SP 705001-SP 705001-SP 705001-SP 1
DESICCANT NOTE 1 NOTE 1 NOTE 1 NOTE 1 NOTE 1 NOTE 1 NOTE 1
DISPLAY BOARD, PANEL 633653 633653 633653 633653 633653 633653 1
DRYER CONTROLLER, NEMA 4
Provide dryer Model and Serial Number 47606394001 47606394001 47606394001 47606394001 47606394001 47606394001 1
to ensure correct confi guration.
FR-1 ELEMENT, CNTRL AIR FILTER/REG 104422 104422 104422 104422 104422 104422 1 1 1 2
FLT-2 ELEMENT, PREFILTER - HIGH EFF EF600H (3) EF600H (4) EF600H (5) EF600H (6) EF600H (7) EF600H (10) (Qty) 1 Set 1 Set 2 Sets
FLT-3 ELEMENT, AFTERFILTER - PARTIC EF600G (3) EF600G (4) EF600G (5) EF600G (6) EF600G (7) EF600G (10) (Qty) 1 Set 1 Set 2 Sets
DPI-2, 3 GAUGE, DIFF PRESSURE, FILTER 633353 633353 633353 633353 633353 633353 2
PI-1, 2, 3 GAUGE, PURGE/TOWER PRESS 631324 631324 631324 631324 631324 631324 3
DR-2, 3 INTERNAL DRAIN, FILTER - - - - - - 2
EXH-1, 2 MUFFLER, PURGE 680455 (2) 680455 (2) 680455 (2) 680455 (4) 680455 (4) 680455 (4) (Qty) (Qty) (Qty) (Qty)
– OVERLAY, CONTROLLER 634083 634083 634083 634083 634083 634083 1
– POWER SUPPLY 47587161001 47587161001 47587161001 47587161001 47587161001 47587161001 1 1 1 1
FX-1A, 2A RETAINER, DES SCREEN UPPER 725269-SP 725269-SP 725269-SP 725151-SP 725151-SP 725270-SP 2
FX-1B, 2B RETAINER, DES SCREEN LOWER 725269-SP 725269-SP 725269-SP 725151-SP 725151-SP 725270-SP 2
FV-1A, 2A VALVE, TOWER INLET 47633580001 47633580001 47633580001 47633581001 47633581001 47633581001 2
FV-1B, 2B VALVE, TOWER PURGE 47590672001 47590672001 47590672001 47633579001 47633579001 47633579001 2
HCV-1 VALVE, PURGE FLOW METERING 680712 680712 680466 680466 680466 680466 1
HCV-2, 3, 4 VALVE, CNTRL AIR, SHUTOFF/BLEED 681621 681621 681621 681621 681621 681621 3
FV-1P, 2P VALVE, CHECK, TOWER PURGE 683983 683983 633943 633943 633943 634098 2
FV-1C, 2C VALVE, CHECK, TOWER OUTLET 632794 632794 633364 633364 633364 633365 2
PSV-1, 2 VALVE, SAFETY/RELIEF, TOWER AD1415 AD1415 AD1415 AD1415 AD1415 AD1415 2
FV-4A, 4B, 4C, 4D VALVE, SOLENOID, CONTROL AIR 47606405001 47606405001 47606405001 47606405001 47606405001 47606405001 4
