Zendure Satellite Monitor CT User Manual

6
Off
L N
KL
Step 3
Clamp CT sensor around service main
Clamp the CT sensor around the service main. Note the K L direction of
energy ow (grid to home). If the installation site uses three phase power
and you have a Zendure SolarFlow or Zendure AIO, clamp the CT sensor
around the same phase as those products.
Connect the AC power cord to the grid single-phase socket
Plug the power harness into the Satellite Monitor CT AC power input
connection until it snaps into place. Then connect the harness plug to a
single-phase power outlet.
Step 4
EN

Zendure Satellite Monitor CT Specifications

General

Brand	Zendure
Model	Satellite Monitor CT
Category	Power Supply
Language	English
