Doc.No.: 08300-007-DE
Page 8 of 16
FIGURE 2
/ FIGUR 2
Eng.:
The cable outer screens is to be terminated as shown. Conductive type of cable ties is recommended to obtain best
possible screen connections.
No.:
Kabelens ytterskjerm skal termineres som vist. Festebånd av ledende materiale bør benyttes for å oppnå best kontakt
mellom skjerm og chassis.
5.0 CABLE REQUIR
EMENTS / KRAV TIL KABEL
Eng.:
To substations: one pair, twisted, outer screen.
If extra signal organ: one pair extra.
To bridge wings: two pairs, individually twisted, outer screen.
Power cables: one pair, gnd.
Minimum conductor area all cable types: 0.75 mm
2
.
IMPORTANT: TO SECURE UN-INTERFERED OPERATION DO
NOT COMBINE SIGNAL CABLES WITH
OTHER CABLE TYPES SUCH AS MAINS SUPPLY.
THE CABLING FOR THE CIS SYSTEM SHOULD BE A SEPARATE NETWORK.
