Zenitel Phontech 9016 - CIS 3101 Technical Specifications; CIS 3102 Technical Specifications

Doc.No.: 08300-007-D
E
Page 13 of 16
Current drain / strømtrekk: 2 A max.
Line capacity / linjekapasitet: 10 lines.
Power amp. capacity / forsterkerkapasitet: 20 W total
Up to 10 W per line.
Frequency range / frekvens område: Better than 400-6000 Hz (-3dB)
Distortion / forvrengning: Better than 2.5% typ.
Extra signal organ output / ekstra signal giver utgang: + 24 VDC, max 150mA
Open collector output to GND
Bridge wing microphone input / Broving mikrofon nivå: 200 Ohm / 10 mV typ.
Bridge wing loudspeaker output / Broving høyttaler utgang: 8 Ohm / 5W typ.
Line level, Stb. Bridge wing Emergency paging level /
Linje nivå, Styrbord broving Nød melding nivå: 775 mV (0dBm) typ.
CIS 3102
Operation voltage / driftsspenning: 24 VDC
Current drain / strømtrekk: 3 A max.
Line capacity / linjekapasitet: 20 lines.
Power amp. capacity / forsterkerkapasitet: 40 W total
Up to 10 W per line.
Frequency range / frekvens område: Better than 400-6000 Hz (-3dB)
Distortion / forvrengning: Better than 2.5% typ.
Extra signal organ output / ekstra signal giver utgang: + 24 VDC, max 150mA
Open collector output to GND
Bridge wing microphone input / Broving mikrofon nivå: 200 Ohm / 10 mV typ.
Bridge wing loudspeaker output / Broving høyttaler utgang: 8 Ohm / 5W typ.
Line level, Stb. Bridge wing Emergency paging level /
Linje nivå, Styrbord broving Nød melding nivå: 775 mV (0dBm) typ.
