CM151 2-5 CA - INSTALLER MENUS
CA CONSUMER CHASSIS
FACTORY MENU RECOMMENDED SETTINGS
ITEM RANGE 25” 27” 32” 36” DESCRIPTION
00 F MODE 0-1 0 0 0 0 Factory mode - perfer to page 2-1
01 PRE PX 0-7 0 0 0 0 Used to store customer menu adjustments
02 V POS 0-30 15 15 15 15 Moves On Screen display vertically
03 H POS 0-45 9 9 9 9 Moves On Screen display horizontally
04 LEVEL 0-2 1 1 1 1
05 BAND 0-7 0 0 0 0 Broadcast Band adjustment
06 AC ON 0-1 0 0 0 0 AC power feature
TECHNICAL SETTINGS
07 RFB PF 0-1 1 1 1 1 Control for brightness in therefore mode
08 3.5T 0-1 1 1 1 1 3.58 MHz Trap
09 RF BRT 0-63 38 33 38 33 Control for brightness in RF mode
10 AX BRT 0-63 38 33 38 33 Control for brightness in AUX mode
11 MAX CON 0-63 63 63 63 63 Control for contrast
12 V SIZE 0-254 145 125 120 174 Vertical Size
13 H SIZE 0-254 0 0 174 120 Horizontal size
14 V PHASE 0-7 2 0 2 1 Shifts picture vertically
15 H PHASE 0-31 14 17 14 14 Shifts picture horizontally
16 AUDLVL 0-63 46 46 46 46 Sound Attenuation
17 RF AGC 0-63 31 31 31 31 Weak channel adjustment
18 H AFC 0-1 1 1 1 1 Horizontal Automatic Frquency control
19 WHCOMP 0-1 0 0 0 0 White compression
20 60HZSW 0-2 2 2 2 2 60 Hertz Switched
21 PIFVCO 1-127 31 31 31 31 PIF Voltage Controlled Oscillator
COLOR TEMP STARTING VALUE
22 R CUT 0-254 0 0 0 0 B&W tracking adjustment
23 G CUT 0-254 0 0 0 0 B&W tracking adjustment
24 B CUT 0-254 0 0 0 0 B&W tracking adjustment
25 G GAIN 0-254 86 103 81 90 B&W tracking adjustment
26 B GAIN 0-254 82 75 75 90 B&W tracking adjustment
27 SCROLL 0-1 0 0 0 0 User Menu scroll type
28 6 KEYS 0-1 0 0 0 0 Keyboard type
AUDIO SETTINGS
29 A ATT 0-15 9 9 9 9 Audio Attenuator
30 A VCO 0-63 31 31 31 31 Audio Decoder Oscillator
31 AFILTER 0-63 31 31 31 31 Audio Filter
32 ASPECTRAL 0-63 31 31 31 31 Adjustment of Stereo seperation
33 WBAND 0-63 31 31 31 31 Wide band Low Frequency Seperation
34 IN OSDC 0-1 0 0 0 0 On Screen Display Internal Oscillator
35 OSD FRAME 0-1 0 0 0 0 On Screen Display Frame
36 ASS ON 0-1 0 0 0 0 Automatic Sleep System
DIFFERENCES FOR 221-1385-01
35 XTAL 0-1 0 0 0 0 External Crystal
INSTALLERS MENU 221-1385 (continued)
Note: If you change the EPROM, change the microprocessor from 221-1385-00 to 221-1385-01
