COMPONENT PARTS LIST
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
CM151 4-18 CA - COMPONENTS
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
SEE REFERENCE CHART ON PAGE 4-12
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3005 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3006 103-00344-06A DIODE, LOW VOLTAGE GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3201 103-00344-06A DIODE, LOW VOLTAGE GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3203 103-00347-03A DIODE, LOW VOLTAGE GENERAL,
SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3204 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3252 103-00344-06A DIODE, LOW VOLTAGE GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3401 103-00588A DIODE, LOW VOLTAGE GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3402 103-00588A DIODE, LOW VOLTAGE GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3403 103-00588A DIODE, LOW VOLTAGE GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3404 103-00588A DIODE, LOW VOLTAGE GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3405 103-00347-03A DIODE, LOW VOLTAGE GENERAL,
SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3406 103-00344-06A DIODE, LOW VOLTAGE GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3407 103-00344-06A DIODE, LOW VOLTAGE GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3408 103-00344-06A DIODE, LOW VOLTAGE GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa EX3401 038-00102 SPARK GAP, HIGH VOLTAGE, 4KV
DC
IZ FX3401 136-00114-23A FUSE, NORMAL LAG, 4 AMP
250V
ABCDEFGHJKLMNOPQRSTUVWXYa FX3401 136-00114-23C FUSE, NORMAL LAG, 4 AMP
250V
IZ FX3402 136-00148-23 FUSE, NORMAL LAG, 3 AMP
250V
ABCDEFGHJKLMNOPQRSTUVWXYa FX3402 136-00148-23C FUSE, NORMAL LAG, 3 AMP
250V
ABCDEFGHIJKLMNOPQRSTUVWXYZa IC0804 126-03700 HEAT SINK, IC, AUDIO
AMPIFIER
ABCDEFGHIJKLMNOPQRSTUVWXYZa IC0804 221-00598-01 INTEGRATED CKT, AUDIO
POWER AMP
FGIPQRSXYZ IC1400 221-01127 INTEGRATED CKT , MTS STEREO
DECODER/VOL.LIMITER AND
BCDEHJKLMNOTUVWa IC1400 221-01382 INTEGRATED CKT , AUDIO
MULTIPLEXING DECODER, USA
DEHLMNOTUVW IC1401 221-01171 INTEGRATED CKT , AUDIO/
VIDEO SWITCH, 2 CHAN/2
POSIT
BCDEHJKLMNOTUVWa IC1402 221-01380 INTEGRATED CKT , STEREO AMP.
AND DC VOL/CONTROL
Z IC2100 126-03626 HEAT SINK, TRANSISTOR,
HORIZONTAL OUTPUT
ABCDEFGHIJKLMNOPQRSTUVWXYa IC2100 126-03626-04 HEAT SINK, TRANSISTOR,
HORIZONTAL OUTPUT
ABCDEFGHIJKLMNOPQRSTUVWXYZa IC2100 221-00992-01 INTEGRATED CKT, VERTICAL
DEFLECTION
HTUVWXY IC2501 221-01393 INTEGRATED CKT, Y/C PIP
CONTROLLER
HTUVWXY IC2502 221-01183 INTEGRATED CKT, ANALOG
MULTIPLEX/DEMULTIPLEX,
TRIP
FGHIPQRSTUVWXYZ IC2901 221-01171 INTEGRATED CKT , AUDIO/
VIDEO SWITCH, 2 CHAN/2
POSIT
HTUVWXY IC2902 221-01171 INTEGRATED CKT , AUDIO/
VIDEO SWITCH, 2 CHAN/2
POSIT
ABCDEFGHIJKLMNOPQRSTUVWXYZa IC6000 126-03446-02 SHIELD, EMI,
MICROPROCESSOR
BCDEJKLMNOa IC6000 221-01384-01 INTEGRATED CKT , 8-BIT
MICROCOMPUTER
AFGIPQRSZ IC6000 221-01384-02 INTEGRATED CKT , 8-BIT
MICROCOMPUTER
HTUVW IC6000 221-01386-01 INTEGRATED CKT , 8-BIT
MICROCOMPUTER
XY IC6000 221-01387-01 INTEGRATED CKT , 8-BIT
MICROCOMPUTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa IC6001 221-00745-04 INTEGRATED CKT , 4K BIT
SERIAL EEPROM
ABCDEFGHIJKLMNOPQRSTUVWXYZa IC6002 221-01177A INTEGRATED CKT , SYSTEM
RESET
ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX2200 221-01165 INTEGRATED CKT , I2C BUS
CONTROL NTSC
ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3400 126-03660-01 HEATSINK, TRANSISTOR
ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3400 223-00028 INTD CKT PKG, HYBRID,
VOLTAGE REGULATOR
ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3401 126-03326-02 HEATSINK, TRANSISTOR
ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3401 221-00213-09 INTEGRATED CKT, 9 VOLT, 1
AMP, LINEAR, REGULATOR
ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3402 126-02131-01 HEAT SINK, TRANSISTOR
ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3402 221-00213 INTEGRATED CKT, 5 VOLT, 1
AMP, LINEAR, REGULATOR
ABCDEJKa IR6000 012-10795 BRACKET, IR DETECTOR
MOUNTING
ABCDEJKa IR6000 162-00046 IR DETECTOR
FGIPQRSXYZ J0001 A-18785-02 JACK ASSEMBLY, 5 PHONO/1
Y-C
DEHLMNOTUVW J0001 A-18785-03 JACK ASSEMBLY, AV, 3 PHONO
ABCDEFGHIJKLMNOPQRSTUVWXYZa J0003M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa J0006M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa J0007M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa J0008M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa J0009M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZ J0010M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa J0012M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa J0015M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
BCJKa J1406M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
BCJKa J1407M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGIJKLMNOPQRSZa J2201M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGIJKLMNOPQRSZa J2202M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
HTUVWXY J2501M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
HTUVWXY J2502M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
HTUVWXY J2504M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
HTUVWXY J2510M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
HTUVWXY J2512M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEHJKLMNOTUVWa J2902M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa KX3401 195-00161 RELAY, SPST, 12 VDC COIL
ABCDEFGHIJKLMNOPQRSTUVWXYZ L1200 020-03907-25A COIL, 120 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L1201 020-04277-09A COIL, 0.82 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L1202 020-04278B COIL, RCF, TUNABLE, 7.0 MM
ABCDEFGHIJKLMNOPQRSTUVWXYZa L1203 020-03907-12A COIL, 10 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L1204 020-04277-39A COIL, 10 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L1205 020-04277-23A COIL, 12 MICROHENRY, RCF,
FIXED
